HE 500 M
Wide Flange Beams
refer to : EN 10365:2017
European standard specifies the nominal dimensions and masses of the hot rolled steel channels, I and H sections.
Dimension : 524x306x21x40
Depth : 524 mm
Width : 306 mm
Web Thickness : 21 mm
Flange Thickness : 40 mm
Root Fillet Radius : 27 mm
Sectional Area : 344.3 cm2
Unit Weight : 270.3 kg/m
