HE 700×352
Wide Flange Beams
refer to : EN 10365:2017
European standard specifies the nominal dimensions and masses of the hot rolled steel channels, I and H sections.
Dimension : 728x308x25x46
Depth : 728 mm
Width : 308 mm
Web Thickness : 25 mm
Flange Thickness : 46 mm
Root Fillet Radius : 27 mm
Sectional Area : 448.6 cm2
Unit Weight : 352.2 kg/m
